Understanding the alkali interaction with the organic functional groups is significant for molecular-level design of potential anode materials.In this work,we investigate the chemical and electronic interactions between Li/Na and PTCDA/PTCDI during the deposition processes. The change of molecular electronic structures has been studied by X-ray photo electron spectroscopy (XPS), ultraviolet photoelectron spectroscopy (UPS), synchrotron-based near edge X-ray absorption fine structure (NEXAFS), and corroborated by density functional theory (DFT) calculations.

MATERIALS FOR HUMANITY (MH 21)

Alkali Metal Storage Mechanism in Organic Semiconductor of PTCDA and PTCDI
