Typical fabrication methods used for laboratory-scale (&lt;1 cm2) investigations of perovskite solar cells do not scale to large-area (&gt;100 cm2) modules required for commercial application- with crystallization control of the active perovskite absorber being particularly challenging. Here, we show that the addition of alkali salts Cs+ and K+ to the perovskite precursor ink used in the scalable slot-die coating can be exploited to control the crystallization of Cs0.15FA0.85Pb(I0.83Br0.17)3 (CsFA), allowing for large-area fabrication of homogeneous and highly crystalline perovskite films. X-ray photoelectron spectroscopy analysis reveals segregation of potassium ions (K+) at the SnO2/perovskite interface, confirming that the additive initially forms nanoclusters in the precursor solution which serves as nucleation sites for subsequent bottom-up crystallization of the perovskite. The highest efficiencies are achieved with the K+ additive: the champion small cell PCE is 18.94% (0.09 cm2) and the mini-module efficiency is 16.22 % at an active area of 57.5 cm2- the highest efficiencies achieved for slot-die coated methylammonium-free perovskites. The small area devices show significantly enhanced operational stability compared to additive-free controls retaining ~72 % of its initial PCE after 426 days (10,224 h) in 30 % relative humidity (RH) and retaining 82% and 54 % of initial PCE after 1,150 h and 958 h at 65 °C and 85 °C. Later, K(add)-CsFA additive based perovskite minimodule retains ~82% of its initial PCE after 200 days (4,800 h) under 30 % RH and the perovskite solar module retains ~50 % of its initial PCE after 560 h without encapsulation under continuous illumination in the dry air environment. We believe that such a controlled “bottom-up crystallization” approach for perovskite film formation is a promising approach for scalability and reproducibility, key for industrializing perovskite photovoltaic technology.
