The increasing demand of permanent magnets (PM) based technology going along with the limitation of global supply of rare-earths (RE) elements drives the development of RE-free PM [1]. Based on the material requirements regarding magnetic properties, costs and criticality, Mn-Al(-C) alloys have been pointed as candidates for PM applications. The hard magnetic properties originate from the metastable τ-phase which is usually formed during annealing from the parent high temperature ε-phase [2,3]. However, the annealing parameters have to be optimized in order to avoid the decomposition of the ferromagnetic phase into the nonmagnetic stable phases in the Mn-Al system. In this context, the Spark Plasma Sintering (SPS) can be a useful technique to optimize this process by combining uniaxial pressure and fast heating/cooling rates due to efficient Joule heating, caused by direct current pulses, and possible side effects related to electric field/current [4]. In this study, we investigate the transformation from ε- to τ-Mn54Al44C2 using the SPS and compared the results with conventional annealing. The ε- to τ-phase transformation has been done by SPS at different temperatures (400, 450, 500 and 550°C) and different times (5 and 15 min). A pure τ-MnAlC is obtained at 500°C/5min (Figure 1 (a)). Below this temperature there is still presence of ε-MnAlC and above we observe the formation of undesired β-phase. On the other hand, conventional heat treatment shows a full transformation at 500°C only after 30 min. Magnetic properties are dependent on the phase formation (Figure 1 (b)), but similar coercivity and saturation magnetization are obtained for the pure τ-MnAlC formed either by SPS or by conventional annealing. However, the SPS method allows to significantly shorter the time necessary to complete the transformation and limits the grain growth.References: [1] K.P. Skokov, O. Gutfleisch, Scripta Mater., 154 289 (2018) [2] V. Øygarden et al., J. Alloys Compd. 779 776 (2019) [3] H. Jian et al., J. Alloys Compd. 622 524 (2015) [4] O. Guillon et al., Adv. Eng. Mater., 16 830 (2014)

MMM 2020

Formation and Magnetic Properties of τ-MnAlC Synthesized by Spark Plasma Sintering Process
