We present a characterization methodology for on-resistance and threshold voltage extraction through pulsed IV, where the transition from off-state to measurement phase is tuned to move from soft- to hard-switching. Results demonstrate that: i) RON may show significant increase (with saturation) moving from soft- to hard-switching; ii) VTH is strongly affected by hard-switching; iii) improved passivation results in lower on-resistance increase; iv) gate field plate length impacts RON increase with marginal effect on VTH shift.

IRPS 2024 Main Conference

Ron and Vth extraction in Hard-Switched E-mode GaN HEMTs: impact of passivation and layout

pulsed iv

hard switching

gan hemts
