Using a W-line with Cu injectors, we analyzed the impact of thermal gradients on Cu interconnects lifetime. Self-heating was experimentally assessed, and Cu temperature was estimated through an electro-thermal model. Experimentally, we find a low EM-EA~0.8eV, suggesting other failure mechanisms. Our 1D physics-based model predicts 3x faster void nucleation for EM+TM and a corrected EA~0.89eV, closer to the measured EM-EA. This finding allows a more reliable lifetime estimation under operating conditions with high thermal gradients.

IRPS 2024 Main Conference

De-coupling Thermo-migration from Electromigration using a dedicated test structure
